mITX-Q170A | mITX-H110A
Mini-ITX | 7./6. Gen. Core™ LGA1151
Limited stock, please contact your sales person.
Mini-ITX Motherboard with 7/6th Generation Intel® Core™, Pentium® or Celeron® processors and Q170 or H110 chipset
mITX-Q170A | mITX-H110A from GigaIPC are not recommended for new designs.
Features:
- mITX-Q170A supports 6/7th Generation Intel® Core™ i3/i5/i7 processors; Q170 Express Chipset
- mITX-H110A supports 6/7th Generation Intel® Core™ i3/i5/i7, Pentium® and Celeron® processors; H110 Express Chipset
- Dual Channel DDR4, 2 x SO-DIMMs
- 2 x GbE LAN ports
- 3 x SATA 6Gb/s ports
- HDMI, Display Port, D-Sub, LVDS/eDP ports for multiple display
- Realtek ALC269 audio codec
- 2 x RS-232/422/485, 5V/12V/RI COM Ports
Ordering Information:
- 9MDQ17BIMR-SI | mITX-Q170A
- 9MDH11LIMR-SI | mITX-H110A
Technical Data
Manufacturer
GigaIPC
Product Series
Motherboard
Product Category
Mini-ITX
CPU Type
- Intel® Core™ i
- Intel® Pentium®
- Intel® Celeron®
CPU
LGA1151
Chipset
- Q170A
- H110A
Memory
max. 32GB 2x DDR4
Temperature Range Top
0...+60°C
Temperature Range Tst
-20...+70°C
Interfaces
eDP
LVDS
HDMI
USB 2.0
RS232/422/485
DisplayPort
Audio
Gigabit LAN
mPCIe
SATA 3.0
PCIe
USB 3.2 Gen1
