IB200

2.5" Single Board Computer AMD RyzenTM Embedded R2000 Series

Data:

• AMD Ryzen™ Embedded R2000 series APU onboard/
  Zen+ up to 4 cores / 8 Threads
• Onboard Memory, DDR4, Max. 8GB
• 2x HDMI 2.0b & LVDS: 5V/3.3V, 24 bit, Dual Channel
  (LVDS: 1920 x 1200 at 60 Hz)
• 2x Giga Lan / 2x USB 3.2 Gen2 (10Gbps) [With PDPC
  support] / 3x USB 2.0 (Pin Header) (Add +5V source
  for Panel)
• 1x M.2 (M-Key, type:2280) & 1x M.2 (E-Key, type: 2230)

Ordering information:
IB200 | R2312 APU
