TX16D209VM0BAB
Internal SAP ID: KO-01-018
JDI's (formerly KOE) 6.4" TFT display TX16D201VM0BAB with XGA resolution and IPS wide viewing angle technology features very high brightness of 1400cd/m² and a wide temperature range of 30 bis +80°C..
It is a perfect alternative to the discontinued Tianma TFT display NL10276BC13-01C.
Technical Data
Manufacturer
JDI
Technology
TFT
Product Series
- TFT Displays
- High Brightness TFTs
Size Diagonal
06.4" (16.256 cm)
Resolution (max)
1024x768
Brightness [cd/m2]
1400
Contrast
1500:1
Backlight
LED
Converter
integriert
Viewing angle U/D/L/R
85/85/85/85
Temperature Range Top
-30...+80°C
Temperature Range Tst
-30...+80°C
Interfaces
LVDS
Power Supply
LCD 3.3V ; Backlight 12V
Format
4:3
Dimensions (LxWxD)
153.0 x 118.0 x 8.7mm
Touch
Optional
