TX26D208VM0AAA
rugged
Internal SAP ID: KO-01-004
JDI's (KOE's) 10.2" TFT display TX26D208VM0AAA with IPS wide viewing angle technology an full-HD resolution is very robust, features high brightness and an extremely wide temperature range (-40 ~ +85°C). and is perfectly suitable for challenging industrial applications.
Exactly matching this display we offer the 10-finger PCAP touch screen TP-DD1020-A00 with I²C and USB interface. Also available as touch film TF-DD1020-A00 with a protective glass designed according to your individual wishes.
Technical Data
Manufacturer
JDI
Technology
TFT
Product Series
- TFT Displays
- High Brightness TFTs
Product Category
rugged
Size Diagonal
10.2" (25.908 cm)
Resolution (max)
1920x1080
Brightness [cd/m2]
1200
Contrast
1000:1
Backlight
LED
Converter
integriert
Viewing angle U/D/L/R
85/85/85/85
Temperature Range Top
-40...+85°C
Temperature Range Tst
-40...+90°C
Interfaces
LVDS
Power Supply
LCD 3.3V ; Backlight 12V
Format
16:9
Dimensions (LxWxD)
241.9 x 147.8 x 12.6mm
Touch
Optional
Specials
vibrations- und schockresistent
